Devinci Chainsaw Deore 12s
$4,599.00
Details
Long Live Chainsaw
Stevie Smith’s love for riding was contagious. Just being in his presence made you want to go fast, whether you were racing or not. We made the Chainsaw to embrace that spirit and carry on his legacy, with an annual donation to the Stevie Smith Legacy Foundation.
Whether you’re lapping the park, lining up for your first DH race or pedalling to the gnarliest trail in town, the only thing stopping this Chainsaw are its brakes. It can handle any trail you throw at it: the aluminum frame is made in Canada and guaranteed for life. It’s compatible with mixed wheels, single and dual crown forks.
Let ‘er rip!
| Frame Size | Small | Medium | Large | X-Large |
|---|---|---|---|---|
| Seat Tube (MM) | 405 | 435 | 450 | 470 |
| Seat Angle (DEG) | 79.9 | 79.4 | 78.9 | 78.4 |
| Head Angle (DEG) | 62.9 | 62.9 | 62.9 | 62.9 |
| Top Tube (MM) | 558 | 586 | 619 | 651 |
| Reach (MM) | 449 | 469 | 494 | 519 |
| Chainstay (MM) | 425 | 430 | 435 | 440 |
| Wheel Base (MM) | 1228 | 1257 | 1292 | 1327 |
| BB Height (MM) | 342 | 342 | 342 | 342 |
| Standover Height (MM) | 717 | 717 | 717 | 717 |
| Stack (MM) | 614 | 623 | 632 | 641 |
| Head Tube (MM) | 95 | 105 | 115 | 125 |
| Rider Height (CM) | 160-170 | 169-179 | 178-188 | 187-198 |
Specs
| Frame | Aluminum Optimum G04 170mm |
|---|---|
| Fork | Rockshox Domain R DebonAir 170 | 1T | 44 Offset |
| Rear Shock | RockShox SuperDeluxe Select R DebonAir | 225x70T |
| Rims | RaceFace ARC30 29 | 30mm inner | TR |
| Hubs |
Front: Formula DC-711 | Sealed | 6bolts | TA 15x110mm Rear: Novatec DH92SB-MS | 6bolts | TA 12x157mm | Microspline |
| Spokes | Sapim Stainless 14G w/Nylok |
| Tires |
Front: Maxxis Minion DHF | 29x2.5WT | 3C | Exo+ | TR | MaxxTerra Rear: Maxxis Minion DHRII | 29x2.4wt | 3C | DD | TR | MaxxGrip |
| Bottom Bracket | Shimano BB MT501 | BSA | 68/73mm |
| Crankset | RaceFace Ride 32T |
| Shifters | Shimano Deore M6100 | 12s | I-spec EV |
| Rear Derailleur | Shimano Deore M6100 | 12s |
| Cassette/Freewheel | Shimano Deore M6100 | 12s | 10-51T | Microspline |
| Chain | KMC X12 | 12s |
| Brakes | Shimano MT520/MT501 | 4 Pistons |
| Rotors | Shimano RT66 | 203mm |
| Handlebars | V2 Pro | B:35mm | R:15mm | W:780mm |
| Tape/Grips | Devinci Performance | w/lock-on |
| Stem | V2 Pro | B:35mm | L:50mm | 0° |
| Headset | FSA Orbit | 1.5 | Zero Stack |
| Seatpost | TranzX | 34.9mm | 1x Lever |
| Saddle | SDG FLY MTN |
| Pedals | Sold separately |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN |
|---|---|---|
| Silver / Small / 29-inch | 883385259092 | FV251102A1 |
| Silver / Medium / 29-inch | 883385258972 | FV251103A1 |
| Silver / Large / 29-inch | 883385259061 | FV251104A1 |
| Silver / X-Large / 29-inch | 883385258811 | FV251105A1 |
| Matcha / Small / 29-inch | 883385258620 | FV251102A3 |
| Matcha / Medium / 29-inch | 883385258583 | FV251103A3 |
| Matcha / Large / 29-inch | 883385258613 | FV251104A3 |
| Matcha / X-Large / 29-inch | 883385258644 | FV251105A3 |
