Details
The Marshall is a Made-in-Canada, made-for-the-people, light-up-the-trails, dual-suspension mountain bike. At its heart, the all-new 130mm travel aluminum frame delivers Split-Pivot performance and reliability with key features like Boost spacing, size-appropriate wheel sizes, a dropper post, frame protection, and a lifetime warranty—all in a more wallet-friendly package. Paired with a 140mm fork and reliable parts, the Marshall delivers no-fuss riding for no-nonsense riders.
Made in Canada Aluminum Frame
Made from 6061-T6 aluminum tubesets for superior durability, incredible stiffness, and a knockout strength-to-weight ratio exclusive to Devinci bikes.
Modern Geometry
A modern geometry featuring a longer reach and slacker head angle for confidently tackling technical sections, while a steeper seat tube angle helps you motor up the climbs.
Lifetime Warranty
Riding passions last a lifetime. Now your bike does too.
Room for a Bottle
All frame sizes have room for at least a standard 500ml bottle with a piggyback shock.
Threaded BB
Threaded BB for headache-free removal and easy maintenance.
Boost 12 x 148mm
Frames designed around Boost 148 offer ample tire clearance so you can take advantage of improved wheel stiffness.
Enduro Bearings
Enduro double-lip sealed bearings for precision movement and superior longevity.
XS | S | M | L | XL | |
---|---|---|---|---|---|
A. Reach | 420mm | 440mm | 460mm | 480mm | 500mm |
B. Stack | 575mm | 585mm | 621mm | 630mm | 639mm |
C. Standover | 717mm | 744mm | 749mm | 767mm | 797mm |
D. Effective Top Tube | 555mm | 579mm | 603mm | 626mm | 650mm |
E. Head Tube Angle | 66.5° | 66.5° | 66.5° | 66.5° | 66.5° |
F. Head Tube Length | 95mm | 105mm | 105mm | 115mm | 125mm |
G. Seat Tube Angle | 76.8° | 76.7° | 77° | 76.9° | 76.8° |
H. Seat Tube Length | 370mm | 400mm | 420mm | 445mm | 495mm |
I. Bottom Bracket Height | 337mm | 337mm | 337mm | 337mm | 337mm |
M. Wheelbase | 1143mm | 1167mm | 1203mm | 1227mm | 1251mm |
O. Chainstay Length | 430mm | 430mm | 435mm | 435mm | 435mm |
Rider Height | 150 -161cm | 160 - 170cm | 169 - 179cm | 178 - 188cm | 187 - 198cm |
Wheel Size | 27.5" | 27.5" | 29" | 29" | 29" |
Size | XS | S | M | L | XL |
---|---|---|---|---|---|
CM | 150-161 | 160-170 | 169-179 | 178-188 | 187-198 |
INCHES | 4'11" - 5'3" | 5'3" - 5'7" | 5'7" - 5'11" | 5'11" - 6'2" | 6'2" - 6'6" |
Specs
Frame | Aluminum Optimum G04 130mm |
---|---|
Fork | RockShox 35 Silver TK Solo Air 140 | 44 Offset |
Rear Shock | Rockshox Deluxe R Debonair | 2T | 210x50 |
Rims | V2 Comp | 29mm inner | TR |
Hubs |
Front: Formula DC-711 | Sealed | 6bolts | TA 15x110mm Rear: Formula MST-148 | Sealed | 6bolts | TA12x148mm | Microspline |
Spokes | Sapim Stainless 14G w/Nylok |
Tires |
Front: Maxxis Minion DHF | 27.5 x 2.5" WT | DualCompound Exo TR Rear: Maxxis Minion DHRII | 27.5 x 2.4" WT | DualCompound Exo TR |
Bottom Bracket | Shimano BB52 | BSA | 68/73mm |
Crankset | Shimano MT510 | 30T |
Shifters | Shimano Deore M6100 | 12s | I-spec EV |
Rear Derailleur | Shimano Deore M6100 | 12s |
Cassette/Freewheel | Shimano M6100 | 12s | 10-51T | Microspline |
Chain | Shimano Deore M6100 | 12s |
Brakes | Shimano Deore M4100/MT420 | 4 Pistons |
Rotors | Shimano RT66 | 180mm |
Handlebars | V2 Pro | B:35mm | R:15mm | W:780mm |
Tape/Grips | Devinci Performance | w/lock-on |
Stem | V2 Pro | B:35mm | L:50mm | 0° |
Headset | FSA Orbit | 1.5 | Zero Stack |
Seatpost | TranzX Dropper | 31.6mm | 1x Lever |
Saddle | Devinci |
Pedals | Sold separately |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Black Edition / X-Small | 883385197646 | FV21052111 | 210000020415 |
Black Edition / Small | 883385198438 | FV21052211 | 210000024362 |
Black Edition / Medium | 883385197684 | FV21052311 | 210000024363 |
Black Edition / Large | 883385198421 | FV21052411 | 210000024364 |
Black Edition / X-Large | 883385198414 | FV21052511 |
